The light weight AC/DC Electromagnetic Yoke is the ideal tool for detection of surface or Sub-surface crocks and flows in any ferromagnetic material. No other low cost, portable equipment offers such versatility Magnetic Particle Inspection. Fast and simple to operate, it is widely used with either dry or wet method fluorescent or non-fluorescent Magnetic powders, in the testing of welds, automotive or railroad components, machine ports, steel and grey iron castings, forgings and in plant inspection, maintenance and repair. A.C. Magnetisation: It creates a surface field which only detects surface cracks. Particularly useful for inspecting thick and irregular sections for surface defects such as fatigue cracks. Best results obtained with dry method. D.C. (Pulsed) Magnetisation: Use of Half wave D.c. magnetization creates pulsing magnetic fields which penetrates the work piece and detects surface and subsurface (slightly) cracks. Pulsing improves particle mobility and sensitivity. Can be used for dry and even wet method Specifications: AC/HWDC Electromagnetic Yoke Mostly used to test the welds, seams etc Common applications include welding, casting, Forged parts, pipes, and any other random inspections. Suitable for Dry and wet method Other Details: Warning before operation see the operation Manual
Use our MTU test block also known as reference block
type 1 to test the concentration of your magnetic powder suspensions, to ensure
optimal error indication while carrying out magnetic particle inspection.
The disc is used to check the performance and sensitivity of of the magnetic particle materials, to allow
you to assess the material degradation and/or bath contamination.
Centrifuge tube is used for checking the concentration of the powder particles in the freshly prepared Bath for MPI. Pear-shaped 100ml glass centrifuge tube is manufactured to meet the requirements of ASTM Standard. The tube is duly graduated and has a least count of 0.1 ml. This ensures the accurate reading of the settling of powder particles.
Centrifuge tube is used for checking the concentration of the powder particles in the freshly prepared Bath for MPI. Pear-shaped 100ml glass centrifuge tube is manufactured to meet the requirements of ASTM Standard. The tube is duly graduated and has a least count of 0.05 ml . This ensures the accurate reading of the settling of powder particles.
The Pie Gauge/Pie Filed Indicator is a tool for quickly verifying the direction of magnetic flux on a surface. It is made from eight ferrous segments, braised into a single piece, providing a star pattern of nonferrous discontinuities. Typically used with dry powders for yoke inspection, the Pie Gauge can be held at any angle and will generate indications perpendicular to the direction of the magnetic flux. A similar test gauge, the Berthold Penetrometer, uses four instead of eight ferrous sections • ASME BPVC Section V Article 7 • ASTM A275 • ASTM E709 • ASTM E1444 • ASTM E3024
